Standard Series, Time Delay Switch, 250V, 6A

Standard Series, Time Delay Switch, 250V, 6A White Electric

Item Number: 319-WE

Timer that is designed to automatically turn off lights after a preset period. Pneumatic switch. Timer range is 30 seconds to 20 minutes. Clipsal 319 series. Colour: White Electric Rated current: 6AX. Operating voltage 250V a.c. 50Hz Note: Requires installation by an appropriately licenced electrician.

Datasheet

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Product brand

Clipsal

Range of product

Series 319

Surface finish

glossy

Physical

Device presentation

basic element with full cover plate

Device mounting

flush

[ue] rated operational voltage

250 V

Rated current

6 A

Reach regulation

Reference contains Substances of Very High Concern above the threshold

Eu rohs directive

Compliant with Exemptions

Mercury free

Yes

Rohs exemption information

Yes

China rohs regulation

Product out of China RoHS scope. Substance declaration for your information

Material

Material

plastic

Others

Package 1 bare product quantity

1

Autonomy

0.0083...0.33 h

Network frequency

50/60 Hz

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

6.8 cm

Package 1 width

9.4 cm

Package 1 length

12.8 cm

Package 1 weight

60 g
Show all specifications
