Standard Series, Caravan Socket Outlet, Auto Switched, IP34, 10A White Electric
Item Number: 415VF-WE
Datasheet
Close
Specifications
Design
Product or component type
socket-outlet
Product brand
Clipsal
Physical
Quantity per set
set of 1
Marking
without marking
Local signalling
without light indicator
Device mounting
flush
Fixing mode
by screws
[in] rated current
10 A
[ue] rated operational voltage
250 V AC
Depth
38 mm
Length
101 mm
Width
80 mm
Fixing center
76 x 65 mm
Standards
AS/NZS 3112|AS 3100|AS 3109|AS/NZS 3122:approval number S/1
Ip degree of protection
IP34
Reach regulation
Free of Substances of Very High Concern above the threshold
Reach free of svhc
Yes
Eu rohs directive
Compliant
Toxic heavy metal free
Yes
Mercury free
Yes
Rohs exemption information
Yes
China rohs regulation
Pro-active China RoHS declaration (out of China RoHS legal scope)
Others
Package 1 bare product quantity
1
Cover type
full cover plate
Socket additional information
with hinged lid
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
6.3 cm
Package 1 width
8.9 cm
Package 1 length
11.6 cm
Package 1 weight
156.0 g
