Specifications
Design
Range
Pro Series
Product or component type
switch
Surface treatment
untreated
Surface finish
glossy
Physical
Number of rocker
2
Installation direction
vertical
Quantity per set
set of 10
Device presentation
complete product
Device mounting
wall
[ue] rated operational voltage
230/240 V
Rated current
20 A/16 AX
Clamping connection capacity
- 1 x 1.5...4 x 1.5 mm² for rigid or stranded cable(s)
- 3 x 2.5 mm² for stranded cable(s)
- 1 x 4 mm² for stranded cable(s)
Fixing mode
by screws
Width
38 mm
Height
113 mm
Depth
40 mm
Net weight
0.063 kg
Relative humidity
10...95 %
Ambient air temperature for operation
0...45 °C
Eu rohs directive
Under investigation
Documents & downloads
hide showFilter items
-
All
-
Certificates (MSDS)
ZIP
Schneider Electric, 40M and 381M switch mechanism, Certificate, RCM, Global Mark Pty LTD
VERSION
1.1
DATE
29 Jul 2024
REVISION
1.1
DOWNLOAD (ZIP) 660.4 KB
ZIP
Iconic 40M switch series, Certificate, RCM, TUV Rheinland Aust. Pty. Ltd.
VERSION
1.1
DATE
23 Feb 2024
REVISION
1.1
DOWNLOAD (ZIP) 1.5 MB
ZIP
RCM Certificate of Approval (Conformity)
VERSION
9.0
DATE
23 Feb 2024
REVISION
9.0
DOWNLOAD (ZIP) 235.7 KB
