Datasheet
For PDLS387A4R-SH
Product Dimensions
Width23.0 mm
Height23.0 mm
Depth8.5 mm
Close
Specifications
Design
Range
PDL Iconic
Aesthetic name
Iconic Styl
Product or component type
rocker
Colour tint
silver shadow (SH)
Product destination
cover frame
Surface finish
satin
Surface treatment
metallic
Physical
Type of packing
polybag
Quantity per set
set of 5
Range compatibility
PDL Iconic rocker
Fixing mode
clip-in
Height
23.0 mm
Width
23.0 mm
Depth
8.5 mm
Net weight
0.03 kg
Ambient air temperature for storage
0...45 °C
Ambient air temperature for operation
0...45 °C
Relative humidity
10...95 %
Reach regulation
Reference contains Substances of Very High Concern above the threshold
Eu rohs directive
Compliant with Exemptions
Mercury free
Yes
China rohs regulation
Product out of China RoHS scope. Substance declaration for your information
Rohs exemption information
Yes
Environmental disclosure
ENVPEP1607003EN
Circularity profile
N/A
Material
Material
anodised aluminium: rocker
