Iconic Styl Cover Plate Cooker Switch 45A

Home ProductsSwitches and SocketsPDL Iconic StylStyl Cover Plate Cooker Switch

Iconic Styl Cover Plate Cooker Switch 45A | Silver Shadow

Item Number: PDLS347C-SH

Where To Buy

Datasheet

PDF datasheet

Download

Product Dimensions

Width icon

Width126.0 mm

Height icon

Height82.0 mm

Depth icon

Depth8.5 mm

See full specifications

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range

PDL Iconic

Aesthetic name

Iconic Styl

Product or component type

cover frame

Colour tint

silver shadow (SH)

Product destination

switch

Surface finish

satin

Surface treatment

metallic

Sustainable offer status

Green Premium product

Physical

Type of packing

polybag

Quantity per set

set of 10

Range compatibility

PDL Iconic switch

Device mounting

flush

Number of rocker

2

Marking

cooker

Installation direction

horizontal/vertical

Fixing mode

clip-on

Height

82.0 mm

Width

126.0 mm

Depth

8.5 mm

Net weight

0.03 kg

Ambient air temperature for storage

0...45 °C

Ambient air temperature for operation

0...45 °C

Relative humidity

10...95 %

Reach regulation

Free of Substances of Very High Concern above the threshold

Reach free of svhc

Yes

Eu rohs directive

Compliant

Toxic heavy metal free

Yes

Mercury free

Yes

Rohs exemption information

Yes

China rohs regulation

 Pro-active China RoHS declaration (out of China RoHS legal scope)

Environmental disclosure

ENVPEP1607003EN

Circularity profile

N/A

Material

Material

anodised aluminium: cover frame

Others

Package 1 bare product quantity

1

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

1.5 cm

Package 1 width

8.17 cm

Package 1 length

12.62 cm

Package 1 weight

54.0 g
