C2000 Series, Single Switch, Vertical Mount, 1 Gang, 250V, 10A

Home ProductsSwitches and SocketsC2000 SeriesSingle Switch

C2000 Series, Single Switch, Vertical Mount, 1 Gang, 250V, 10A White Electric

Item Number: C2031VA-WE

Switch assembly. C2000 cover plate, grid and switch mechanism are included. Suitable for 1-gang vertical installations. Assembled with plate. Clipsal C2000. Colour: White Electric Rated current: 10AX. Operating voltage 250V a.c. 50Hz. Note: Requires installation by an appropriately licenced electrician.

Where To Buy

Datasheet

PDF datasheet

Download

Barcode

Qty UoM EAN Colour
-
-
-
See all

Specifications

Design

Range of product

Classic Series C2000

Product brand

Clipsal

Surface finish

glossy

Sustainable offer status

Green Premium product

Physical

Device presentation

basic element with full cover plate and grid

Number of poles

1

Device mounting

flush

Number of rocker

1

Local signalling

without

[ue] rated operational voltage

250 V AC

Rated current

10 A|8 AX, fluorescent lamp

Marking

without marking

Fixing mode

by screws

Actuator

rocker

Switch function

1-pole

Standards

AS/NZS 60669.1

Reach regulation

Reference contains Substances of Very High Concern above the threshold

Eu rohs directive

Compliant with Exemptions

Mercury free

Yes

Rohs exemption information

Yes

China rohs regulation

Product out of China RoHS scope. Substance declaration for your information

Environmental disclosure

ENVPEP120809EN

Circularity profile

N/A

Others

Package 1 bare product quantity

1

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

3 cm

Package 1 width

7.6 cm

Package 1 length

11.7 cm

Package 1 weight

68 g
Show all specifications
