Specifications
Design
Range of product
600 Series
Product or component type
switch
Colour tint
white
Surface finish
gloss
Sustainable offer status
Green Premium product
Physical
Control type
rocker
Installation direction
vertical|horizontal
Length
23 mm
Width
23 mm
Depth
26 mm
Rated current
16 AX|20 A
[ue] rated operational voltage
250 V
Number of gangs
1 gang
Number of poles
1
Mounting mode
front
Ambient air temperature for operation
-10...40 °C
Eu rohs directive
Compliant
Toxic heavy metal free
Yes
Mercury free
Yes
Rohs exemption information
Yes
China rohs regulation
Pro-active China RoHS declaration (out of China RoHS legal scope)
Environmental disclosure
ENVPEP111024EN
Circularity profile
ENVEOLI110713EN
Material
Material
PC (polycarbonate)
Others
Package 1 bare product quantity
1
Network type
AC
Motor m-rating as3133
M60
Network number of phases
1 phase
Cable cross section
2 x 2.5...2.5 mm²|4 x 1.5...1.5 mm²
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
3 cm
Package 1 width
2.3 cm
Package 1 length
2.3 cm
Package 1 weight
15.41 g
