600 Series Switch Module 2-Way 16A 1P + Lid | White

Item Number: PDL681M16HFWH

Switch mechanism with a hinge. Single-pole switch. 600 Series mechanism. PDL 600. Colour: White Rated current: 16 A / 16AX. Operating voltage 240V a.c. 50Hz Note: Requires installation by an appropriately licenced electrician.

Where To Buy

Datasheet

PDF datasheet

Download

Barcode

Qty UoM EAN Colour
-
-
-
See all

Specifications

Design

Range of product

600 Series

Product or component type

switch

Colour tint

white

Surface finish

gloss

Physical

Control type

rocker

Installation direction

horizontal|vertical

Rated current

16 A|16 AX|8 AX

[ue] rated operational voltage

230/240 V

Number of poles

1

Reach regulation

Reference contains Substances of Very High Concern above the threshold

Eu rohs directive

Compliant with Exemptions

Mercury free

Yes

China rohs regulation

Product out of China RoHS scope. Substance declaration for your information

Rohs exemption information

Yes

Material

Material

PC (polycarbonate)

Others

Package 1 bare product quantity

1

Network type

AC

Motor m-rating as3133

M50

Cable cross section

2 x 2.5...2.5 mm²|4 x 1.5...1.5 mm²

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

3.5 cm

Package 1 width

2.5 cm

Package 1 length

2.5 cm

Package 1 weight

15.094 g
