Datasheet
Close
Specifications
Design
Range of product
600 Series
Product or component type
switch
Colour tint
white
Surface finish
gloss
Physical
Installation direction
vertical
Width
37 mm
Height
23 mm
Rated current
8 kA
[ue] rated operational voltage
230/240 V
Mounting mode
front
Ambient air temperature for operation
-40...80 °C
Quantity per set
set of 10
Type of packing
carton
Reach regulation
Free of Substances of Very High Concern above the threshold
Reach free of svhc
Yes
Eu rohs directive
Compliant
Toxic heavy metal free
Yes
Mercury free
Yes
Rohs exemption information
Yes
China rohs regulation
Pro-active China RoHS declaration (out of China RoHS legal scope)
Circularity profile
N/A
Material
Material
PC (polycarbonate)
Others
Package 1 bare product quantity
1
Network frequency
50 Hz
Network number of phases
1 phase
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
2.5 cm
Package 1 width
11.0 cm
Package 1 length
10.0 cm
Package 1 weight
0.029 kg
