DALIControl, Din-Mount Power Supply and Serial Interface, 2 DALI Lines
Item Number: DCDALCIP250-2
Datasheet
Specifications
Design
Range of product
Range
Product brand
Product or component type
Device application
Physical
Output current
Output current
Local signalling
Mounting support
Reach regulation
Reach free of svhc
Eu rohs directive
Toxic heavy metal free
Mercury free
Rohs exemption information
China rohs regulation
Others
Package 1 bare product quantity
[us] rated supply voltage
Supply circuit type
Number of outputs
Number of modules
Unit type of package 1
Number of units in package 1
Package 1 height
Package 1 width
Package 1 length
Package 1 weight
Documents & downloads
hide show-
All
-
Product Brochures
-
CAD Files and Packs
-
Specification Guide
-
Application Notes
-
Certificates (MSDS)
-
Software - Release
Plug & Play Solution - DALIinfinity Soft Wiring 5 Pole, 24678
VERSION
1.0
DATE
29 Sep 2023
REVISION
1.0
Think differently about lighting control. DALIcontrol 30 Series Mech Range, 151007
VERSION
1.0
DATE
29 Sep 2023
REVISION
1.0
DALIcontrol - Commercial Offices and Emergency and Exit Light Monitoring, 24576
VERSION
1.0
DATE
29 Sep 2023
REVISION
1.0
DALIcontrol Native Solution Typical Schematic, 119204
VERSION
1.0
DATE
29 Sep 2023
REVISION
1.0
DALI Buildings DALIBuildings-V2.2.1 with SQL Server and Release Notes
VERSION
1.0
DATE
29 Sep 2023
REVISION
1.0
DALI Buildings with SQL Server and Release Notes
VERSION
1.0
DATE
29 Sep 2023
REVISION
1.0
DALI Buildings with SQL Server and Release Notes
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
DALI Buildings with SQL Server and Release Notes
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
DALI Buildings with SQL Server and Release Notes
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
DALI Buildings with SQL Server and Release Notes
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
DALI Buildings with SQL Server and Release Notes
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
DALI Buildings with SQL Server and Release Notes
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
DALI Buildings with SQL Server and Release Notes
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
DALI Buildings with SQL Server and Release Notes
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
DALI Buildings with SQL Server and Release Notes
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
DALI Buildings with SQL Server and Release Notes
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
DALI Buildings with SQL Server and Release Notes
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
Energy Controller Payback Analysis software V1.0.0
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
EmergencyMonitor V2.1
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
DALISimpleWizard V1.3.0.82
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
DALISimpleWizard V1.2.0.78
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
DALISimpleWizard V1.1.0.77
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
DALISimpleWizard V1.0.0.71
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
DALI Control AutoCAD Templates V1.0.2
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
DALICommissioningWizard V2.3.0.33
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
DALIBuildings V2.1.4
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
DALIBuildings V2.1.3
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
DALIBuildings V2.1.2
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
DALIBuildings V2.1.1
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
DALIBuildings V2.1.0
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
DALIBuildings V2.0.9
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
DALIBuildings V2.0.8
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
DALIBuildings V2.0.7
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
DALIBuildings V2.0.6
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
DALIBuildings V2.0.5
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
DALIBuildings V2.0.4
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
DALIBuildings V2.0.10
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
DALI Control Visio Stencils V1.0.2
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
DALI Buildings with SQL Server and Release Notes
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
C-Bus Visio Stencils V1.0.2
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
C-Bus AutoCAD Templates V1.0.2
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
BuildingMonitor V6.0.472
VERSION
1.0
DATE
21 Jul 2023
REVISION
1.0
DALI Buildings V2.2.3 Software Release notes
VERSION
2.0
DATE
09 Jun 2022
REVISION
2.0
Frequently Asked Questions
hide showSuppose the following happens when connecting the DCCABKIT6 cable between Laptop and DALIcontrol Duo Mode 3 Power Supply (DCDALCIP250-2).
In Device Manager find something like
The cable has likely been used with some other product that has recognised the FDTI chip and installed this LibUSB driver which is not recognised by the Simple Wizard which sees a different device ID
BEFORE GOING FURTHER REALISE THAT ONCE COMPLETE THE OTHER DEVICE WILL NO LONGER FIND ITS REQUIRED DRIVER.
Right click on this entry in the Device Manager and select Properties from the menu
And proceed to the Driver tab
…and select <Update Driver>
… and Select <Browse my computer for Drivers>
Select <Let me pick from a list of available drivers on my computer>
With this next Dialog un-tick the Show compatible hardware
In this case you should see Manufacturer FTDI and Select from the Model USB Serial Port which should start the install finishing with…
From here you should now be able to connect.
It is important to note that when connecting to the DALIcontrol Duo Mode 3 Power Supply (DCDALCIP250-2) with the DCCABKIT6 programming cable and running DCBMWizard or SimpleWizard that the power supply be in mode 1. To achieve this on the DCDALCIP250-2 press and hold the <ON A> button and momentarily press the <TEST A> button. The Line A indicator will single pulse 5x to indicate the mode.
If there is a compatible driver installed you can try tick Show Compatible hardware, then try selecting one of the drivers below.
If there are no drivers to be found on the Computer in question it is then possible to download the software by going to the following on your web browser https://support.arduino.cc/hc/en-us/articles/4411305694610-Install-or-update-FTDI-drivers and follow the instructions laid out.
Also go to https://ftdichip.com/drivers/ and follow up with https://ftdichip.com/document/installation-guides/
Dimension wise - 8 module vs 6 modules wides
Built in DALI PS - Separate vs Build in dali power supply
C-Bus Current draw 32mA vs 20 mA
Dali Compatible Vs Dali2 Compliance…
The replacement is Dali Control Din-Mount Power Supply & Serial Interface, Two Dali lines
Part number DCDALCIP250-2
https://www.clipsal.com/products/detail?CatNo=DCDALCIP250-2&itemno=DCDALCIP250-2&tab-document-1=0
Hardware required:
Dalicontrol Dual power supply & SCI - DCDALCIP250-2
USB to RJ45 Programming Cable - DCCABKIT6
PC/Laptop with DALI Simple Wizard Software
Unfortunately DCDALCIP250-2 are not DALI2 certified
There is no certainty that it will work, because there were no tests for bus power supplies before DALI-2.
DALI devices (switches and sensors) are a big risk. There is a big chance both our switches/sensors and DALI2 devices will clash. The switches/sensors use the extended DALI range but this is not part of DALI2. If DALI2 devices use this same range there could be comms issues.
