PDL Lighting and Accessories Batten Lampholder Bayonet Base 150W 230/240VAC | White
Item Number: PDL29LWH
Datasheet
Close
Specifications
Design
Range of product
PDL Lighting and Accessories
Product or component type
button module
Colour tint
white
Surface finish
glossy
Physical
Load type
150 W lamp
Quantity per set
set of 20
Type of packing
carton
[ue] rated operational voltage
230/240 V AC 50 Hz
Fixing mode
by screws
Device mounting
surface
Fixing center
50 mm
Connections - terminals
4 x 1 mm screw terminal
Reach regulation
Reference contains Substances of Very High Concern above the threshold
Eu rohs directive
Pro-active compliance (Product out of EU RoHS legal scope)
Mercury free
Yes
China rohs regulation
Product out of China RoHS scope. Substance declaration for your information
Rohs exemption information
Yes
Material
Material
thermoplastic
Others
Package 1 bare product quantity
1
Network number of phases
1 phase
Diameter
66 mm
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
6.7 cm
Package 1 width
6.7 cm
Package 1 length
7.0 cm
Package 1 weight
0.055 kg
