56 Series Twin Socket 10A 250V 1-Phase 3- Flat Pin IP66 | Grey
Item Number: PDL56SO3102LEGY
Specifications
Design
Range of product
56 Series™
Product brand
PDL
Product or component type
socket-outlet
Colour tint
grey
Surface finish
gloss
Physical
Quantity per set
set of 4
Type of packing
carton
Installation direction
vertical
Width
95 mm
Height
95 mm
Depth
35 mm
Rated current
10 A
[ue] rated operational voltage
250 V
Number of gangs
1 gang
Pin number
3
Mounting mode
surface mounted
Fixing center
84 x 84 mm
Ip degree of protection
IP66
Ambient air temperature for operation
-40...55 °C
Reach regulation
Reference contains Substances of Very High Concern above the threshold
Eu rohs directive
Compliant with Exemptions
Rohs exemption information
Yes
China rohs regulation
Product out of China RoHS scope. Substance declaration for your information
Material
Material
polycarbonate
Device composition
flat pin
Others
Package 1 bare product quantity
1
Network frequency
50 Hz
Network number of phases
1 phase
Cable cross section
0.75...6 mm²
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
5 cm
Package 1 width
9.5 cm
Package 1 length
19 cm
Package 1 weight
365 g
