56 Series Socket 10A 250V 3-Flat Pin IP66, Chemical-Resistant Grey

Home ProductsIndustrial56 SeriesSocket

56 Series Socket 10A 250V 3-Flat Pin IP66, Chemical-Resistant Grey | Chemical Grey

Item Number: PDL56SO310LECG

Where To Buy

Datasheet

PDF datasheet

Download

Product Dimensions

Width icon

Width95.0 mm

Height icon

Height95.0 mm

Depth icon

Depth60.0 mm

See full specifications

Barcode

Qty UoM EAN Colour
-
-
-
See all

Specifications

Design

Range

56 Series

Product or component type

socket-outlet

Market segment

industry|utility|small commercial

Physical

Mounting mode

surface mounted

[in] rated current

10 A

Pin number

3 pins

[ue] rated operational voltage

250 V

Connections - terminals

screw terminals 1.5-6 mm² rigid or stranded cable

Wire stripping length

10 mm

Net weight

0.185 kg

Height

95.0 mm

Width

95.0 mm

Depth

60.0 mm

Standards

AS/NZS 3123

Ip degree of protection

IP66 conforming to AS 60529

Ambient air temperature for operation

-25...75 °C

Ambient air temperature for storage

-25...75 °C

Reach regulation

Reference contains Substances of Very High Concern above the threshold

Eu rohs directive

Compliant with Exemptions

Mercury free

Yes

Rohs exemption information

Yes

China rohs regulation

Product out of China RoHS scope. Substance declaration for your information

Material

Material

polycarbonate: cover

Contacts material

pins: brass

Others

Package 1 bare product quantity

1

Device short name

PDL56SO310LECG

Plug, socket category

low voltage

Poles description

1P + N + E

Network type

AC

Outlet standard deviation

Australian/New Zealand

Plug, socket, control station shape

straight

Shape of pin

flat

Network frequency

50 Hz

Targeted country

Australia|New Zealand

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

6 cm

Package 1 width

9.5 cm

Package 1 length

9.5 cm

Package 1 weight

185 g
Show all specifications
